The TBS2102B Oscilloscope with a 9-inch WVGA display, 5 million point record length and 2 GS/s sample rate, capture and display significantly more signal to help you debug and validate the designs faster. Easily and confidently analyse your signals with new on-waveform cursor readouts and 32 automated measurements, each with informative tips. The TekVPI® probe interface supports traditional passive BNC probes, but also enables wide application coverage with the latest active voltage probes and current probes
Key performance specifications

• 2 analog channel models
• 100 MH bandwidth models up to 2 GS/s sampling rate
• 5 M record length on all channels
• 5 year warranty

Key features

• 9-inch WVGA color display with 15 horizontal grids shows 50% more signal
• TekVPI probe interface supports active, differential, and current probes with automatic scaling and units
• New front-end design enables more accurate measurements32 automated measurements, and FFT function for quick waveform analysis
• Search and Mark features for easy identification of events that occur in the acquired wave form Help Every where provides helpful on-screen tips for new users
• Built-in Scope Intro handbook provides operating instructions and oscilloscope fundamentals
• The instrument user interface and the front panel overlay is translated into 10 languages

• Availability: 10 In Stock
• Model: TBS2102B
• Brand:
